层级性公共服务设施空间可达性研究——以北京市综合性医疗设施为例

doi:10.11821/dlyj201604011

摘要/Abstract

摘要：

分层诊疗制度有利于充分利用已有的医疗资源,是医疗卫生体制改革的重要内容。但是目前关于医疗设施可达性的研究普遍存在两个问题：没有考虑医疗机构的层级性;没有考察城市的多模态道路设施对医疗机构空间可达性的影响。通过构建两阶段的两步移动搜寻法,同时利用多模态网络数据集的网络分析法,研究在不同转诊率条件下北京城六区医疗设施的空间可达性。研究发现：① 医疗设施的总体空间可达性随转诊率的提高呈现倒U型走势;60%左右的转诊率情况下医疗设施总体空间可达性最高。② 在60%的转诊率条件下,考虑地下交通时的医疗设施总体空间可达性比不考虑地下交通时提高约9.81%,街道医疗设施空间可达性方差下降8.58%。这说明地铁建设不仅可以提升医疗设施总体的空间可达性,还可以降低街道之间空间可达性的不均衡性。③ 医疗资源“倒金字塔”型分布是制约分层就诊体系建立的关键,建立分层就诊体系需要同时调整医疗资源在不同等级医院之间的分布。

关键词: 多模态网络数据集, 二阶段两步移动搜寻法, 层级性公共服务设施, 空间可达性

Abstract:

Hierarchical diagnosis and treatment system is a key part of medical and health system reform which can take full use of medical resources. But most of current research about accessibility of medical facilities has two drawbacks: Firstly, they did not consider the level of medical institutions and the stratification treatment of patients; secondly, the influence of multi-modal road facilities on spatial accessibility of medical institutions is not investigated. Here we conduct research on the spatial accessibility of medical institutions at different levels of medical institutions and different referral rates by using the two-step floating catchment area method and multi-modal network dataset. The conclusions are as follows: Firstly, the overall spatial accessibility of medical facilities shows the trend of the inverted U with the increase of referral rate, and when the referral rate was 60% the spatial accessibility of medical institutions comes to a head; Secondly, when the referral rate was 60%, the spatial accessibility of medical institutions considering the ground transportation and underground transportation is 9.81% higher than that considering the ground transportation only, and the variance of accessibility of medical institutions in the streets decreased by 8.58%; in other words, the subway can not only improve the overall spatial accessibility of medical facilities, but also reduce the imbalance of spatial accessibility of the streets; Thirdly, the "Inverted Pyramid" distribution of medical resources is the foundation of hierarchical diagnosis and treatment system.

Key words: multi-mode network data set, two-step 2SFCA, hierarchy public service facilities, spatial accessibility

钟少颖, 杨鑫, 陈锐. 层级性公共服务设施空间可达性研究——以北京市综合性医疗设施为例[J]. 地理研究, 2016, 35(4): 731-744.

Shaoying ZHONG, Xin YANG, Rui CHEN. The accessibility measurement of hierarchy public service facilities based on multi-mode network dataset and the two-step 2SFCA:A case study of Beijing's medical facilities[J]. GEOGRAPHICAL RESEARCH, 2016, 35(4): 731-744.

图/表 21

图1

图2

表1

图3

图4

图5

表2

表3

图6

图7

表4

表5

图8

图9

图10

图11

图12

图13

图14

图15

图16

参考文献 26

[1]	宋正娜, 陈雯. 基于潜能模型的医疗设施空间可达性评价方法. 地理科学进展, 2009, 28(6): 848-854. doi: 10.11820/dlkxjz.2009.06.003
	[Song Zhenga, Chen Wen.Measuring spatial accessibility to health care facilities based on potential model. Progress in Geography, 2009, 28(6): 848-854.] doi: 10.11820/dlkxjz.2009.06.003
[2]	宋正娜, 陈雯, 车前进, 等. 基于改进潜能模型的就医空间可达性度量和缺医地区判断: 以江苏省如东县为例. 地理科学, 2010, 30(2):213-219.
	[Song Zhengna, Chen Wen, Che Qianjin, et al.Measurement of Spatial accessibility to health care facilities and defining health professional shortage areas based on improved potential model: A case study of Rudong county in Jiangsu province. Scientia Geographica Sinica, 2010, 30(2): 213-219.]
[3]	陈洁, 陆锋, 程昌秀. 可达性度量方法及应用研究进展评述. 地理科学进展, 2007, 26(5): 100-110. doi: 10.3969/j.issn.1007-6301.2007.05.011
	[Chen Jie, Lu Feng, Cheng Cangxiu, et al.2007. Advance in accessibility evaluation approaches and applications. Progress in Geography, 2007, 26(5): 100-110.] doi: 10.3969/j.issn.1007-6301.2007.05.011
[4]	王法辉. 基于GIS的数量方法与应用. 姜世国, 滕俊华译. 北京: 商务印书馆, 2011.
	[Wang Fahui.Quantitative Methods and Application in GIS. Translated by Jiang Shiguo, Teng Junhua. Beijing: The Commercial Press, 2011.]
[5]	魏冶, 修春亮, 高瑞, 等. 基于高斯两步移动搜索法的沈阳市绿地可达性评价. 地理科学进展, 2014, 33(4): 479-487. doi: 10.11820/dlkxjz.2014.04.005
	[Wei Ye, Xiu Chunliang, Gao Rui, et al.Evaluation of green space accessibility of Shengyang using Gaussian based 2-step floating catchment area method. Progress in Geography, 2014, 33(4): 479-487.] doi: 10.11820/dlkxjz.2014.04.005
[6]	Wang F H, Luo W.Assessing spatial and nonspatial factors for healthcare access: towards and integrated approach to defining health professional shortage areas. Health & Place, 2005, 11(2): 131-146.
[7]	Gibin M, Longley P, Atkinson P.Kernel density estimation and percent volume contours in general practice catchment area analysis in urban areas. In: Proceedings of the GIScience Research UK Conference, 2007: 121-125.
[8]	陈晨, 修春亮. 基于交通网络中心性的长春市大型综合医院空间可达性研究. 人文地理, 2014, 29(5): 81-87.
	[Chen Chen, Xiu Chunliang.Spatial accessibility of large central hospitals in Changchun city center based in street network centrality. Human Geography, 2014, 29(5): 81-87.]
[9]	Porta S, Latora V, Wang F H, et al.Street centrality and the location of economic activities in Barcelona. Urban Studies, 2012, 49(7): 1471-1488. doi: 10.1177/0042098011422570
[10]	陶卓霖, 程杨, 戴特奇. 北京市养老设施空间可达性评价. 地理科学进展, 2014, 33(5): 616-624. doi: 10.11820/dlkxjz.2014.05.003
	[Tao Zhuolin, Chen Yang, Dai Teqi.Measuring spatial accessibility to residential care facilities in Beijing. Progress in Geography, 2014, 33(5): 616-624.] doi: 10.11820/dlkxjz.2014.05.003
[11]	胡瑞山, 董锁成, 胡浩. 就医空间可达性分析的两步移动搜索法: 以江苏省东海县为例. 地理科学进展, 2012, 31(12): 1600-1607. doi: 10.11820/dlkxjz.2012.12.005
	[Hu Ruishan, Dong Suocheng, Hu Hao, et al.A two-step floating catchment area method for measuring spatial accessibility to primary healthcare service in China: A case study of Donghai county in Jiangsu province. Progress in Geography, 2012, 31(12): 1600-1607.] doi: 10.11820/dlkxjz.2012.12.005
[12]	陈志芬, 顾林生, 陈晋, 等.城市应急避难场所层次布局研究(1): 层次性分析. 自然灾害学报. 2010, 19(6): 151-155.
	[Chen Zhifeng, Gu Linsheng, Chen Jin, et al.Study on hierarchical location of urban emergency shelters(I): Hierarchy analysis. Journal of Natural Disasters, 2010, 19(6): 151-155.]
[13]	Rongjie Yu, Mohamed Abdel-Aty.Using hierarchical Bayesian binary probit models to analyze crash injury severity on high speed facilities with real-time traffic data. Accident Analysis and Prevention. 2014, 62(6): 161-167. doi: 10.1016/j.aap.2013.08.009 pmid: 24172082
[14]	Reza Zanjirani Farahani, Masoud Hekmatfar.Hierarchical facility location problem: Models, classification, techniques, and applictions. Computes & Industrial Engineering. 2014, 68(5): 104-117.
[15]	国家卫计委主任. 《分级诊疗指导意见》将于今年出台. 凤凰财经,, 2015-04-04.
	[Director of the State Planning Commission. Grading Diagnosis and Treatment Guidance to be issued this year. Phoenix Finance, , 2015-04-04.]
[16]	中华人民共和国国务院新闻办公室. 将建立分级诊疗体系纳入医改重点工作. 中国政府网,, 2015-05-22.
	[Information Office of the State Council of the People's Republic of China: A grading system to be focused on medical care reform. Chinese Government Network, , 2015-05-22.]
[17]	北京市卫生和计划生育委员会. 北京市卫生事业发展统计公报. , 2014-05-15.
	[Beijing Municipal Health and Family Planning Commission. Statistical Bulletin on the Development of Health Undertakings in Beijing. , 2014-05-15.]
[18]	北京市卫生和计划生育委员会. 北京市卫生统计年鉴(2013). 北京: 北京科学技术出版社, 2014.
	[Beijing Municipal Health and Family Planning Commission. Beijing Municipal Health Statistics Yearbook(2013). Beijing: Beijing Science and Technology Press, 2014.]
[19]	北京市人力资源和社会保障局. 2014年北京市基本医疗保险定点医疗机构名单. 2014, 2015-05-04.
	[Beijing Municipal Bureau of Human Resources and Social Security, Beijing basic medical insurance designated medical institutions list. , 2015-05-04.]
[20]	北京市统计局. 北京市2010年人口普查资料. 北京: 中国统计出版社, 2012.
	[Beijing Municipal Bureau of Statistics. Beijing Census Data of 2010. Beijing: China Statistics Press, 2012.]
[21]	Radke J, Mu L.Spatial decomposition, modeling and mapping service regions to predict access to social programs. Geographic Information Sciences, 2000, 6(2): 105-112. doi: 10.1080/10824000009480538
[22]	Luo W, Wang F H.Measure of spatial accessibility to healthcare in a GIS environment: Synthesis and a case study in Chicago. Environment and Planning B: Planning and Design, 2003, 30(6): 865-884.
[23]	北京市交通委员会. 2014 , 2015-06-01. [Beijing Municipal Transportation Commission. Beijing Municipal Transportation Development Report (2014), , 2015-06-01.]
[24]	邓羽, 蔡建明, 杨振山, 等. 北京城区交通事件可待性测度及其空间特征分析. 地理学报, 2012, 67(2): 169-178.
	[Deng Yu, Cai Jianming, Yang Zhenshan, et al.Measuring time accessibility with its spatial characteristics in urban areas of Beijing. Acta Geographica Sinica, 2012, 67(2): 169-178.]
[25]	Luo W.Using a GIS-based floating catchment method to access areas with shortage of physicians. Health & Place, 2004, 10(1): 1-11.
[26]	Cheng Y, Rosenberg M W, Wang W Y, et al.Aging, health and place in residential care facilities in Beijing, China. Social Science & Medicine, 2011, 72(3): 365-372. doi: 10.1016/j.socscimed.2010.10.008 pmid: 21109338

	机构数（个）	编制床位（张）	出院人次（万人次）	医师日均担负住院床日
三级医院	79	62158	212.4	1.8
二级医院	113	26345	50.7	1.4
一级医院	371	15092	12.2	1.1

	三级医院	二级医院	一级医院
机构数	64	68	182
最大值	协和医院（1970）	北京丰台医院（790）	朝阳区第三医院（127）
最小值	北京电力医院（370）	瑞尔口腔医院（15）	丰台兴隆医院（12）
平均值	906	233	52

	三级医院	二级医院	一级医院
机构数	64	68	182
最大值	协和医院（4899）	北京丰台医院（1655）	朝阳区第三医院（256）
最小值	中国中医科学院眼科医院（291）	北京石景山妇幼保健院（55）	北京宣武区证仁医院（21）
平均值	1755	425	62

地铁线路	线路里程（km）	运行时间(min)	运行速度（km/h）
地铁1号线	46.6	90	31.07
地铁2号线	23	42	32.86
地铁4号线	49.4	83	35.71
地铁10号线	57.1	90	38.07
地铁5号线	27.3	50	32.76
地铁6号线	42.6	70	36.51
地铁7号线	22.7	43	31.67
8号线	26	45	34.67
9号线	15.6	31	30.19
13号线	40.5	86	28.26
15号线	40.8	58	42.21
房山线	24.6	32	46.13
昌平县	31.9	26	73.62
亦庄线	23.3	32	43.69
