气溶胶对北京地区云和降水影响的模拟研究

doi:10.11821/dlyj201610010

摘要/Abstract

摘要：

利用中尺度气象模式WRF中一个含有云凝结核CCN活化过程的双参数云微物理方案（NSSL 2-mom+ccn）,研究不同气溶胶导致的初始CCN浓度对云物理和降水过程的影响。完整地模拟了北京市2015年7月16-17日一次典型的从小雨到暴雨连续降水过程,包括降水主要集中的时间段,雨带的西北—东南走向,降水初期普降小雨、后期转变为中到大雨甚至局部地区出现暴雨,24小时最大累积降水量可以达到65 mm,模拟结果与实测符合较好。模拟得到的区域平均累积降水量随着气溶胶的增加而减少,与其他研究根据地面降水与能见度资料统计分析的结论相一致。比较详细地给出了气溶胶对云的微物理结构、水成物时空分布以及微物理过程的转化率的影响。

关键词: 气溶胶, 云, 降水, 数值模拟, 北京

Abstract:

In this paper, the influence of initial CCN concentration on the physical and precipitation processes of cloud was numerically studied by using mesoscale model WRF. A two parameter cloud micro physics scheme (2-mom+ccn NSSL) containing CCN activation process of cloud condensation nuclei is utilized to investigate the impacts of different aerosol backgrounds on the cloud microphysical processes and precipitation. A typical precipitation event near Beijing (July 16-17, 2015), which was formatted as a drizzle case and then developed into heavy precipitation, was simulated in order to examine the sensitivity of aerosol pollution. Controlled experiment captured the characters of this rainfall case very well. Rainfall rate peak in the time series and its varying tendency and moving direction of precipitation strength center were modeled with reliable accuracy. The modeled average precipitation rate decreased with rising aerosol background concentration, which is consistent with studies of some other authors. Structure of cloud system, temple and spatial variation of hydrometeor categories and strength of their sink and source terms are compared and analyzed. Our numerical simulation can completely simulate the whole process of the precipitation, including main precipitation-concentrated period of time, the rain belt in the northwest-southeast direction, precipitation at the beginning of the heavy rain, the late shift to rain or even local rainstorm. Simulation results show that the maximum cumulative precipitation of 24 hours can reach 65 mm, which is in good agreement with the measured data, and the effect of aerosol on precipitation efficiency is different in different precipitation stages. We found that when the initial CCN concentration is higher, the maximum precipitation efficiency occurs in the light rain stage, and the precipitation efficiency is reduced in the rainstorm period. There was no significant change in the precipitation range of the three initial CCN concentrations, but the location of the strong precipitation center shifted from the southwest to the northeast of Beijing. Our simulations also show that the regional mean accumulated precipitation decreases with increasing aerosol, which is consistent with the conclusions of other authors based on the statistical analysis of the ground precipitation and visibility data. Effect of aerosol on cloud micro physical structure, hydrometeor spatial and temporal distribution and conversion of microphysical processes were also given in detail. The results show that in both of early or late precipitation, the background aerosol cloud water content in the air were increased. Our research work is preliminary, but it can be used to carry out a more detailed study of the coupling chemistry model WRF-Chem. Due to the fact that the influence of aerosol on cloud and precipitation is very complex, the relevant observational data is still lacking. Therefore, the research on this aspect is still continuing to carry out extensive and in-depth study in the future.

Key words: numerical simulation, aerosol, cloud, precipitation, Beijing

师宇, 楼小凤, 王广河. 气溶胶对北京地区云和降水影响的模拟研究[J]. 地理研究, 2016, 35(10): 1912-1924.

Yu SHI, Xiaofeng LOU, Guanghe WANG. Numerical simulation of the effect of aerosol on cloud and precipitation in Beijing[J]. GEOGRAPHICAL RESEARCH, 2016, 35(10): 1912-1924.

图/表 9

表1

不同水成物的基本参数"

水成物种类	$ν$	$μ$	$α$	密度（kg/m^-3）
云滴	0	1	$3 ν + 2$	1000
雨滴	-0.8	1	$3 ν + 2$	1000
冰晶	0	1	$3 ν + 2$	900
雪	-0.8	1	$3 ν + 2$	100
霰	-2/3	1/3	0	300~900
雹	-2/3	1/3	1	500~900

表1

图1

图2

图3

图4

图5

图6

表2

表3

参考文献 19

[1]	Ramanathan V, Crutzen P J, Kiehl J T, et al.Aerosols, climate, and the hydrological cycle. Science, 2001, 294(5549):2119-2124. doi: 10.1126/science.1064034 pmid: 174893265202520318
[2]	范泽孟, 岳天祥, 陈传法, 等. 中国降水未来情景的降尺度模拟. 地理研究, 2012, 31(12): 2283-2291.
	[Fan Zemeng, Yue Tianxiang, Chen Chuanfa, et al.Downscaling simulation for the scenarios of precipitation in China. Geographical Research, 2012, 31(12): 2283-2291.]
[3]	孔钦钦, 葛全胜, 席建超, 等. 中国重点旅游城市气候舒适度及其变化趋势. 地理研究, 2015, 34(12): 2238-2246. doi: 10.11821/dlyj201512003
	[Kong Qinqin, Ge Quansheng, Xi Jianchao, et al.Thermal comfort and its trend in key tourism cities of China. Geographical Research, 2015, 34(12): 2238-2246.] doi: 10.11821/dlyj201512003
[4]	洪延超, 雷恒池. 云降水物理和人工影响天气研究进展和思考. 气候与环境研究, 2012, 17(6): 951-967. doi: 10.3878/j.issn.1006-9585.2012.06.32
	[Hong Yanchao, Lei Hengchi.Research advance and thinking of the cloud precipitation physics and weather modification. Climatic and Environmental Research, 2012, 17(6): 951-967.] doi: 10.3878/j.issn.1006-9585.2012.06.32
[5]	杨慧玲, 肖辉, 洪延超. 气溶胶对云宏微观特性和降水影响的研究. 气候与环境研究, 2011, 16(4): 525-542. doi: 10.3878/j.issn.1006-9585.2011.04.13
	[Yang Huiling, Xiao Hui, Hong Yanchao.Progress in impacts of aerosol on cloud properties and precipitation. Climatic and Environmental Research, 2011, 16(4): 525-542.] doi: 10.3878/j.issn.1006-9585.2011.04.13
[6]	Kai Sun, Hongnian Liu, Aijun Ding, et al.WRF-Chem simulation of a severe haze episode in the Yangtze River Delta. China.Aerosol and Air Quality Research. doi: 10.4209/aaqr.2015.04.0248, 2016.
[7]	朱格利, 林万涛, 曹艳华. 用 WRF模式中不同云微物理参数化方案对华南一次暴雨过程的数值模拟和性能分析. 大气科学, 2014, 38(3): 513-523. doi: 10.3878/j.issn.1006-9895.2013.13202
	[Zhu Geli, Lin Wantao, Cao Yanhua.Numerical simulation of a rainstorm event over South China by using various cloud microphysics parameterization schemes in WRF model and its performance analysis. Chinese Journal of Atmospheric Sciences, 2014, 38(3): 513-523.] doi: 10.3878/j.issn.1006-9895.2013.13202
[8]	张兰, 张宇飞, 林文实, 等. 空气污染对珠江三角洲一次大暴雨影响的数值模拟. 热带气象学报, 2015, 31(2): 264-272. doi: 10.16032/j.issn.1004-4965.2015.02.013
	[Zhang Lan, Zhang Yufei, Lin Wenshi, et al.Numerical simulation of air pollution impact on heavy rainfall over the Pearl River Delta. Journal of Tropical Meteorology, 2015, 31(2): 274-272.] doi: 10.16032/j.issn.1004-4965.2015.02.013
[9]	王坤, 张飞民, 孙超, 等. WRF-WSM3微物理方案在青藏高原地区暴雪模拟中的改进及试验. 大气科学, 2014, 38(1):101-109. doi: 10.3878/j.issn.1006-9895.2013.12170
	[Wang Kun, Zhang Feimin, Sun Chao, et al.Development and validation of WRF-WSM3 scheme in simulation of snowstorm in the Tibetan Plateau. Chinese Journal of Atmospheric Sciences, 2014, 38(1): 101-109.] doi: 10.3878/j.issn.1006-9895.2013.12170
[10]	何宏让, 魏绍远, 黄云贵. 初始云滴浓度(CCN)对对流性降水作用的数值试验. 气象科学, 1998, 18(1): 10-19.
	[He Hongrang, Wei Shaoyuan, HuangYungui. The numerical test of initial cloud droplet concentration (CCN) effect on convectional precipitation. Scientia Meteorologica Sinica, 1998, 18(1): 10-19.]
[11]	Pruppacher H R, Klett J D, Wang P K.Microphysics of clouds and precipitation. Aerosol Science and Technology, 1998, 28(4): 381-382.
[12]	岳治国, 刘晓东, 梁谷. 气溶胶对北京地区不同类型云降水影响的数值模拟. 高原气象, 2011, 30(5): 1356-1367.
	[Yue Zhiguo, Liu Xiaodong, Liang Gu.Numerical simulation of influence of aerosols on different cloud precipitation types in Beijing area. Plateau Meteorology, 2011, 30(5): 1356-1367.]
[13]	Meyers M P, DeMott P J, Cottion W R. New primary ice-nucleation parameterizations in an explicit cloud model. Journal of Applied Meteorology, 1992, 31(7): 708-721. doi: 10.1175/1520-0450(1992)0312.0.CO;2
[14]	Ziegler C L.Retrival of thermal and microphysical variables in observed convective storms. Part I: Model development and preliminary testing. Journal of the Atmospheric Sciences, 1985, 42(11): 1487-1509. doi: 10.1175/1520-0469(1985)0422.0.CO;2
[15]	Edward R M, Ziegler C L.Simulated electrification of a small thunderstorm with two-moment bulk microphysics. American Meteorological Society, 2010, 67(1): 171. doi: 10.1175/2009JAS2965.1
[16]	段婧, 毛节泰. 华北地区气溶胶对区域降水的影响. 科学通报, 2008, 53(23): 2947-2955.
	[Duan Jin, Mao Jietai.The influence of aerosol of regional precipitation in North China. Chinese Science Bulletin, 2008, 53(23): 2947-2955.]
[17]	顾震潮. 云雾降水物理基础. 北京: 科学出版社, 1980.
	[Gu Zhenchao.Cloud and Precipitation Physics. Beijing: Science Press, 1980.]
[18]	肖辉, 银燕. 污染气溶胶对山西一次降水过程影响的数值模拟. 大气科学, 2011, 35(2): 235-246. doi: 10.3878/j.issn.1006-9895.2011.02.04
	[Xiao Hui, Yin Yan.A numerical study of polluted aerosol effects on precipitation in Shanxi province. Chinese Journal of Atmospheric Sciences, 2011, 35(2): 235-246.] doi: 10.3878/j.issn.1006-9895.2011.02.04
[19]	Lim K S, Hong S, Yum S S, et al.Aerosol effects on the development of a supercell storm in a double-moment bulk-cloud microphysics scheme. Journal of Geophysical Research Atmospheres, 2011, 116(D2): 3-25. doi: 10.1029/2010JD014128

雨滴的主要源项	物理意义	16日12时微物理过程转化率最大值				17日05时微物理过程转化率最大值
雨滴的主要源项	物理意义	正常		中度污染	重度污染	正常	中度污染	重度污染
		（1500）	（5000）	（8000）		（1500）	（5000）	（8000）
qracw	雨滴碰并云滴	0.065	0.064	0.054		0.163	0.115	0.036
qraci	雨滴收集冰晶粒子	8.23×10^-4	7.06×10^-4	2.97×10^-4		1.48×10^-3	3.3×10^-4	4.15×10^-5
qrcnw	云雨的自动转化	2.83×10^-3	1.398×10^-3	2.86×10^-3		2.75×10^-2	1.61×10^-2	9.23×10^-3
qhmlr	霰的融化	0.186	0.24	0.24		0.114	0.152	0.067
qsmlr	雪的融化	0.113	0.109	0.10		0.061	0.055	0.034

霰的主要源项	物理意义	16日12时微物理过程转化率最大值				17日05时微物理过程转化率最大值
霰的主要源项	物理意义	正常		中度污染	重度污染	正常	中度污染	重度污染
		（1500）	（5000）	（8000）		（1500）	（5000）	（8000）
qhaci	霰收集冰晶	2.106×10^-3	1.509×10^-3	1.19×10^-3		2.89×10^-4	7.643×10^-4	2.652×10^-4
qhcni	冰晶向霰的转化	1.526×10^-3	9.386×10^-4	6.799×10^-4		4.695×10^-5	1.296×10^-4	7.452×10^-5
qhcns	雪向霰的转化	3.376×10^-2	4.986×10^-2	5.4×10^-2		1.282×10^-2	1.428×10^-2	1.038×10^-2
qhacs	霰碰并雪	6.102×10^-2	6.401×10^-2	6.246×10^-2		2.681×10^-2	3.524×10^-2	1.297×10^-2
qhacw	霰碰并过冷云滴	0.107	0.146	0.144		0.062	0.129	0.06
qhacr	霰碰并过冷雨滴	0.023	0.015	0.017		0.057	0.031	0.065
qhdpv	霰的凝华增长	5.669×10^-3	6.762×10^-3	7.119×10^-3		3.082×10^-3	4.644×10^-3	1.925×10^-3
qrfrz	雨滴的冻结	1.014×10^-7	5.339×10^-8	3.879×10^-8		2.626×10^-4	1.206×10^-5	2.921×10^-10
