围垦及米草入侵下江苏中部滨海湿地土地利用/覆被类型动态变化

doi:10.11821/dlyj201708007

摘要/Abstract

摘要：

通过1979年、1991年、2003年和2015年四期的遥感影像,研究1979-2015年间江苏中部滨海湿地的围垦及米草入侵的动态变化及二者影响下土地利用/覆被类型的演化过程。结果表明：1979-2015年,围垦和米草边界总体上不断向海推进,不同岸段推进速度存在差异。围垦面积持续加速增长,各段平均增速为3.43 km²/yr,米草面积在1991-2003年间增速最快,各段平均增速0.89 km²/yr,2002年以后增速下降,为-0.03 km²/yr。芦苇滩涂和碱蓬滩涂转化为围垦的面积占围垦土地来源的比例持续下降,米草滩涂和光滩的这一比例持续上升,对米草滩涂的围垦主要位于方塘河口以北,对光滩的围垦主要位于方塘河口以南。芦苇滩涂、碱蓬滩涂和光滩对米草滩涂面积的贡献为：光滩>碱蓬滩涂>芦苇滩涂。研究区演化路径总体呈现光滩—盐生植被—围垦的方向,但存在缩短趋势;米草入侵挤占了本地盐生植被的扩张空间。

关键词: 滨海湿地, 土地利用/覆被, 围垦, 米草入侵, 演化方向, 江苏

Abstract:

Duo to the combined influence of human activities and natural factors, coastal wetlands in Jiangsu province has undergone rapid change in recent years. This article examines the evolution and spatial distribution of wetlands in central Jiangsu province between 1979 and 2015 through analysis of Landsat TM images. The land use/cover changes induced by reclamation and Spartina alterniflora invasion from 1979 to 2015 (1979, 1991, 2003 and 2015) were detected. The results indicated that the areas of reclamation and Spartina alterniflora in four periods extended to the sea at most locations, while the extending speed varied spatially. The reclamation area continued to be enlarged at an accelerated speed, mainly concentrated in between Wanggang port and Xiaoyangkou port. The reclamation area of each section between Wanggang port and Xiaoyangkou port increased by 3.43 km²/yr on average. The area of Spartina alterniflora increased rapidly during the period of 1991-2003, with a rate of 0.89 km²/yr at each section. However, the rate declined to -0.03 km²/yr during 2003-2015. The proportions of reclamation converted from Pragmites communis declined from 71.30% in 1979-1991 to 9.74% in 2003-2015. The proportions of reclamation evolved from Spartina alterniflora and bare flat increased to 37.98% and 30.90%, respectively. Evolution of Spartina alterniflora to reclamation mainly occurred to the north of Fangtang estuary, while evolution of bare flat to reclamation mainly occurred to the south of Fangtang estuary. Bare flat was the largest source of Spartina alterniflora, followed by Suaeda gsalsa, and Pragmites communis was the smallest. The main area of Spartina alterniflora invasion to bare flat was found from Xinyang estuary to Liangduo estuary. The coastal wetlands evolution of central Jiangsu showed a general trend from bare flat→halophytic vegetation→reclamation, but there was a significant shortening trend due to accelerating reclamation. The invasion of Spartina alterniflora has occupied the living space of local halophytic vegetation.

Key words: coastal wetlands, land use/cover, reclamation, Spartina alterniflora invasion, evolution direction, Jiangsu

金宇, 高吉喜, 周可新, 穆少杰. 围垦及米草入侵下江苏中部滨海湿地土地利用/覆被类型动态变化[J]. 地理研究, 2017, 36(8): 1478-1488.

Yu JIN, Jixi GAO, Kexin ZHOU, Shaojie MU. Dynamic of land use/cover changes under reclamation and Spartina alterniflora invasion in Jiangsu central coastal wetlands[J]. GEOGRAPHICAL RESEARCH, 2017, 36(8): 1478-1488.

图/表 10

表1

图1

图2

图3

表2

图4

图5

表3

表4

表5

参考文献 32

[1]	Kline J D, Swallow S K.The demand for local access to coastal recreation in southern New England. Coastal Management, 1998, 26(3): 177-190. doi: 10.1080/08920759809362351
[2]	Mulder J P M, Hommes S, Horstman E M. Implementation of coastal erosion management in the Netherlands. Ocean & Coastal Management, 2011, 54(12): 888-897. doi: 10.1016/j.ocecoaman.2011.06.009
[3]	Sellamuttu S S, Finlayson C M, Nagabhatla N, et al.Linkages between changes in land cover (use) patterns, local perceptions and livelihoods in a coastal wetland system in Sri Lanka. Journal of the National Science Foundation of Sri Lanka, 2011, 39(4): 391-402. doi: 10.4038/jnsfsr.v39i4.3887
[4]	Arena S, Battisti C, Carpaneto G M.The ecological importance of wetlands for aerial insectivores (swifts, martins and swallows) along the Tyrrhenian coast. Rendiconti Lincei, 2011, 22(4): 395-402. doi: 10.1007/s12210-011-0147-z
[5]	翟可, 刘茂松, 徐驰, 等. 盐城滨海湿地的土地利用/覆盖变化. 生态学杂志, 2009, 28(6): 1081-1086.
	[Zhai Ke, Liu Maosong, Xu Chi, et al.Land use/cover change in Yancheng coastal wetland. Chinese Journal of Ecology, 2009, 28(6): 1081-1086.]
[6]	刘青松, 李杨帆, 朱晓东. 江苏盐城自然保护区滨海湿地生态系统的特征与健康设计. 海洋学报, 2003, 25(3): 143-148.
	[Liu Qingsong, Li Yangfan, Zhu Xiaodong.Charaeteristics of coastal wetland ecosystems and their healthy design: A case study from Yancheng Natural Reserve, Jiangsu province, China. Acta Oceanologica Sinica, 2003, 25(3): 143-148.]
[7]	张华兵, 刘红玉, 李玉凤, 等. 盐城海滨湿地景观演变关键土壤生态因子与阈值研究. 生态学报, 2013, 33(21): 6975-6983. doi: 10.5846/stxb201301150096
	[Zhang Huabing, Liu Hongyu, Li Yufeng, et al.Analysis on landscape pattern change and its driving forces of Yancheng National Natural Reserve. Acta Ecologica Sinica, 2013, 33(21): 6975-6983.] doi: 10.5846/stxb201301150096
[8]	廖华军, 李国胜, 王少华, 等. 近30年苏北滨海滩涂湿地演变特征与空间格局. 地理科学进展, 2014, 33(9): 1209-1217. doi: 10.11820/dlkxjz.2014.09.008
	[Liao Huajun, Li Guosheng, Wang Shaohua, et al.Evolution and spatial patterns of tidal wetland in North Jiangsu province in the past 30 years. Progress in Geography, 2014, 33(9): 1209-1217.] doi: 10.11820/dlkxjz.2014.09.008
[9]	Yao H.Characterizing landuse changes in 1990-2010 in the coastal zone of Nantong, Jiangsu province, China. Ocean & Coastal Management, 2013, 71: 108-115. doi: 10.1016/j.ocecoaman.2012.09.007
[10]	张登荣, 许思莹, 谢斌, 等. 近40年椒江—台州湾滩涂围垦土地利用变化的遥感调查. 国土资源遥感, 2016, 28(1): 101-106. doi: 10.6046/gtzyyg.2016.01.15
	[Zhang Dengrong, Xu Siying, Xie Bin, et al.Land use change of reclaimed mud flats in Jiaojiang-Taizhou Estuary in the past 40 years based on remote sensing technology. Remote Sensing for Land and Resources, 2016, 28(1): 101-106.] doi: 10.6046/gtzyyg.2016.01.15
[11]	张晓祥, 严长清, 徐盼, 等. 近代以来江苏沿海滩涂围垦历史演变研究. 地理学报, 2013, 68(11): 1549-1558. doi: 10.11821/dlxb201311010
	[Zhang Xiaoxiang, Yan Changqing, Xu Pan, et al.Historical evolution of tidal flat reclamation in the Jiangsu coastal areas. Acta Geographica Sinica, 2013, 68(11): 1549-1558.] doi: 10.11821/dlxb201311010
[12]	王艳芳, 沈永明. 盐城国家级自然保护区景观格局变化及其驱动力. 生态学报, 2012, 32(15): 4844-4851. doi: 10.5846/stxb201111241794
	[WangYanfang, Shen Yongming. Analysis on landscape pattern change and its driving forces of Yancheng National Natural Reserve. Acta Ecologica Sinica, 2012, 32(15): 4844-4851.] doi: 10.5846/stxb201111241794
[13]	方仁建, 沈永明, 时海东. 基于围垦特征的海滨地区景观格局变化研究: 以盐城海岸为例. 生态学报, 2015, 35(3): 641-651.
	[Fang Renjian, Shen Yongming, Shi Haidong.The changes of coastal wetland landscape pattern based on the characteristics of reclamation: A case study in coastal wetland of Yancheng, Jiangsu province, China. Acta Ecologica Sinica, 2015, 35(3): 641-651.]
[14]	李建国, 濮励杰, 徐彩瑶, 等. 1977-2014年江苏中部滨海湿地演化与围垦空间演变趋势. 地理学报, 2015, 70(1): 17-28. doi: 10.11821/dlxb201501002
	[Li Jianguo, Pu Lijie, Xu Caiyao, et al.The changes and dynamics of coastal wetlands and reclamation areas in central Jiangsu from 1977 to 2014. Acta Geographica Sinica, 2015, 70(1): 17-28.] doi: 10.11821/dlxb201501002
[15]	Li J G, Pu L J, Zhu M, et al. Evolution of soil properties following reclamation in coastal areas: A review. Geoderma, 2014, 226-227(1): 130-139. doi: 10.1016/j.geoderma.2014.02.003
[16]	Yin A J, Zhang M, Gao C, et al.Salinity evolution of coastal soils following reclamation and intensive usage, Eastern China. Environmental Earth Sciences, 2015, 75(18): 1281-1292. doi: 10.1007/s12665-016-6095-2
[17]	黄翀, 刘高焕, 张海龙, 等. 黄河河口湿地景观变化影响丹顶鹤生境的评价分析. 地球信息科学学报, 2009, 11(4): 491-497. doi: 10.3969/j.issn.1560-8999.2009.04.012
	[Huang Chong, Liu Gaohuan, Zhang Hailong, et al.Wetland land scape dynamics in the Yellow River Mouth: Imlications for conservation. Geo-Information Science, 2009, 11(4): 491-497.] doi: 10.3969/j.issn.1560-8999.2009.04.012
[18]	许艳, 濮励杰. 江苏海岸带滩涂围垦区土地利用类型变化研究: 以江苏省如东县为例. 自然资源学报, 2014, 29(4): 643-652.
	[Xu Yan, Pu Lijie.The variation of land use pattern in tidal flat reclamation zones in Jiangsu coastal area: A case study of Rudong county of Jiangsu province. Journal of Natural Resources, 2014, 29(4): 643-652.]
[19]	张华兵, 刘红玉, 侯明行. 人工管理和自然驱动下盐城海滨湿地互花米草沼泽演变及空间差异. 生态学报, 2013, 33(15): 4767-4775. doi: 10.5846/stxb201205050649
	[Zhang Huabing, Liu Hongyu, Hou Minghang.Spatiotemporal characteristics of Spartina alterniflora marsh change in the coastal wetlands of Yancheng caused by natural processes and human activities. Acta Ecologica Sinica, 2013, 33(15): 4767-4775.] doi: 10.5846/stxb201205050649
[20]	左平, 刘长安, 赵书河, 等. 互花米草属植物在中国海岸带的分布现状. 海洋学报, 2009, 31(5): 101-111.
	[Zuo Ping, Liu Chang'an, Zhao Shuhe, et al. Distribution of Spartina plantations along the China's coast. Acta Oceanologica Sinica, 2009, 31(5): 101-111.]
[21]	张忍顺, 沈永明, 陆丽云, 等. 江苏沿海互花米草(Spartina alterniflora)盐沼的形成过程. 海洋与湖沼, 2005, 36(4): 358-366. doi: 10.3321/j.issn:0029-814X.2005.04.011
	[Zhang Renshun, Shen Yongming, Lu Liyun, et al.Formation of Spartina alterniflora salt marsh on Jiangsu coast, China. Oceanologia et Limnologia Sinica, 2005, 36(4): 358-366.] doi: 10.3321/j.issn:0029-814X.2005.04.011
[22]	朱冬, 高抒. 江苏中部海岸互花米草扩展对滩涂围垦的响应. 地理研究, 2014, 33(12): 2382-2392. doi: 10.11821/dlyj201412015
	[Zhu Dong, Gao Shu.The expansion of Spartina alterniflora marsh in response to tidal flat reclamation, central Jiangsu coast, eastern China. Geographical Research, 2014, 33(12): 2382-2392.] doi: 10.11821/dlyj201412015
[23]	左平, 吴其江. 江苏盐城滨海湿地生态系统与管理. 北京: 中国环境科学出版社, 2014.
	[Zuo Ping, Wu Qijiang.Coastal Wetland Ecosystem and Management in Yancheng, Jiangsu Province: A Case Study in Jiangsu Yancheng National Rare Birds Natural Reserve. Beijing: China Environment Science Press, 2014.]
[24]	Gao S, Du Y F, Xie W J, et al.Environment-ecosystem dynamic processes of Spartina alterniflora salt-marshes along the eastern China coastlines. Science China: Earth Sciences, 2014, 57(11): 2567-2586. doi: 10.1007/s11430-014-4954-9
[25]	左平, 李云, 赵书河, 等. 1976年以来江苏盐城滨海湿地景观变化及驱动力分析. 海洋学报, 2012, 34(1): 101-108.
	[Zuo Ping, Li Yun, Zhao Shuhe, et al.Landscape changes of Jiangsu Yancheng coastal wetlands and their driving forces since 1976. Acta Oceanologica Sinica, 2012, 34(1): 101-108.]
[26]	刘春悦, 张树清, 江红星, 等. 江苏盐城滨海湿地外来种互花米草的时空动态及景观格局. 应用生态学报, 2009, 20(4): 901-908.
	[Liu Chunyue, Zhang Shuqing, Wang Hongxing, et al.Spatiotemporal dynamics and landscape pattern of alien species Spartina altemiflora in coastal wetlands of Jiangsu province, China. Chinese Journal of Applied Ecology, 2009, 20(4): 901-908.]
[27]	周汝佳, 张永战, 何华春. 基于土地利用变化的盐城海岸带生态风险评价. 地理研究, 2016, 35(6): 1017-1028. doi: 10.11821/dlyj201606002
	[Zhou Rujia, Zhang Yongzhan, He Chunhua.Ecological risk assessment based on land use changes in the coastal area in Yancheng city. Geographical Research, 2016, 35(6): 1017-1028.] doi: 10.11821/dlyj201606002
[28]	朱萌, 马孝义, 刘雪娇. 基于马尔科夫模型的武功县土地利用/覆被动态变化研究. 水土保持研究, 2013, 20(5): 64-68.
	[Zhu Meng, Mao Xiaoyi, Liu Xuejiao.Dynamic changes of land use/cover based on Markov model in Wugong County, Shaanxi province. Research of Soil and Water Conservation, 2013, 20(5): 64-68.]
[29]	刘秀娟, 高抒, 汪亚平. 淤长型潮滩剖面形态演变模拟:以江苏中部海岸为例. 地球科学: 中国地质大学学报, 2010, 35(4): 542-550. doi: 10.3799/dqkx.2010.070
	[Liu Xiujuan, Gao Shu, Wang Yaping.Modeling the shore-normal profile shape evolution for an accretional tidal flat on the central Jiangsu coast. Earth Science: Journal of China University of Geosciences, 2010, 35(4): 542-550.] doi: 10.3799/dqkx.2010.070
[30]	张忍顺. 苏北黄河三角洲及滨海平原的成陆过程. 地理学报, 1984, 39(2): 173-184.
	[Zhang Renshun.Land-forming history of the Huanghe River Delta and coastal plain of North Jiangsu. Acta Geographica Sinica, 1984, 39(2): 173-184.]
[31]	王磊, 张明娟, 刘茂松, 等. 近30多年江苏省滨海淤长型滩涂中农业/养殖塘动态. 湿地科学, 2013, 11(2): 178-185.
	[Wang Lei, Zhang Mingjuan, Liu Maosong, et al.Dynamics of agricultural/aquacultural lands in aggradational littoral beaches in Jiangsu province in recent 30 years. Wetland Science, 2013, 11(2): 178-185.]
[32]	王聪, 刘红玉. 江苏淤泥质潮滩湿地互花米草扩张对湿地景观的影响. 资源科学, 2014, 36(11): 2413-2422.
	[Wang Cong, Liu Hongyu.The impact of Spartina Alterniflora expansion on vegetation landscapes in the Yancheng tidal flat wetland. Resources Science, 2014, 36(11): 2413-2422.]

成像载体	传感器	行/列号	成像时间	空间分辨率(m)
Landsat3	MSS	128/37	1979-5-25	78
Landsat5	TM	119/37	1991-4-02	30
Landsat5	TM	119/37	2003-10-28	30
Landsat8	OLI	119/37	2015-10-13	30

不同围垦形式	1979年	1991年	2003年	2015年
农田（km²）	350.98	631.30	660.99	776.78
盐田（km²）	23.02	42.63	46.83	49.97
养殖塘（km²）	30.26	188.04	571.39	721.77

1991年	1979年
1991年	养殖塘	农田	盐田	河流沟渠	茅草滩涂	芦苇滩涂	碱蓬滩涂	米草滩涂	光滩
养殖塘	17.64	18.04	0.4	1.03	0.12	67.18	56.8		15.53
农田	3.05	331.19	0.46	1.58	1.32	243.36	41.03		4.41
盐田	9.03	0	18.84	0	0	8.25	5.82		0.69
河流沟渠	0	0.22	0	4.14	0.01	1.84	1.27		3.85
茅草滩涂	0	0.21	0	0.09	0	2.73	0.01		0.07
芦苇滩涂	0.45	0.63	0.51	4.99	0	107.19	91.49		75.89
碱蓬滩涂	0.04	0	0.03	0.02	0	24.61	157.61		32.84
米草滩涂	0	0.22	0	4.14	0.01	1.27	1.84		3.85
光滩	0.04	0	2.79	3.11	0	50.71	85.76		237.27

2003年	1991年
2003年	养殖塘	农田	盐田	河流沟渠	茅草滩涂	芦苇滩涂	碱蓬滩涂	米草滩涂	光滩
养殖塘	139.22	71.27	0.07	0.32	0.00	128.23	115.43	14.45	90.23
农田	34.40	544.77	0.00	0.73	2.48	64.49	8.94	0.00	3.47
盐田	0.10	0.99	42.56	0.00	0.00	3.16	0.00	0.00	0.00
河流沟渠	0.07	1.96	0.00	9.48	0.00	0.44	0.16	0.10	10.33
茅草滩涂	0.18	0.04	0.00	0.00	0.47	2.15	2.18	0.00	0.27
芦苇滩涂	0.22	1.60	0.00	0.11	0.14	57.80	10.90	0.42	7.60
碱蓬滩涂	0.48	0.80	0.00	0.72	0.00	6.27	50.70	7.50	71.31
米草滩涂	1.68	5.58	0.00	1.86	0.02	9.62	19.43	5.01	151.51
光滩	0.40	0.28	0.00	7.18	0.00	2.39	20.47	0.95	422.91

2015年	2003年
2015年	养殖塘	农田	盐田	河流沟渠	茅草滩涂	芦苇滩涂	碱蓬滩涂	米草滩涂	光滩
养殖塘	352.23	104.82	29.76	1.17	4.52	11.08	44.85	99.38	58.23
农田	177.82	532.73	0.50	1.73	0.26	19.42	8.69	20.73	13.65
盐田	0.01	0.00	16.43	0.00	0.00	0.39	6.59	0.35	26.12
河流沟渠	1.76	6.78	0.00	7.75	0.00	0.78	0.49	2.05	6.30
茅草滩涂	0.62	0.58	0.00	0.34	0.01	0.29	0.52	1.20	7.55
芦苇滩涂	18.94	15.17	0.12	1.40	0.33	42.43	19.15	15.61	14.87
碱蓬滩涂	5.33	0.04	0.00	2.14	0.00	1.33	37.42	8.41	120.40
米草滩涂	1.45	0.00	0.00	3.45	0.00	2.37	19.79	45.40	92.59
光滩	0.76	0.34	0.00	5.81	0.00	0.69	5.10	1.53	397.13
