小区域癌症数据典型空间插值方法比较研究

doi:10.11821/dlyj020200680

摘要/Abstract

摘要：

癌症已成为危害全球居民健康的重大民生问题,选取合适的空间插值方法分析小区域癌症数据的空间特征可对区域性癌症防控工作的有效开展提供依据。本研究以湖南省苏仙区2012和2016年以村为单位的肺癌死亡率数据为研究对象,以平均误差和均方根误差为评价指标,对反距离加权（IDW）、普通克里金（OK）、趋势面分析（TSA）、多元线性回归（MLR）与协同克里金（CK）五种典型空间插值方法进行精度效果对比及参数优选,并结合不同插值方法的优缺点,确定癌症数据的最优插值方法。结果表明：插值精度方面,CK法的均方根误差最小、插值精度最高,OK、IDW（幂值=1）和MLR次之,TSA（阶数=5）最低;插值效果方面,五种插值方法的实测值和预测值均显著相关,除CK外,其它四种方法均对死亡率低估程度较大,CK和OK插值结果的空间分布效果更好。同时考虑空间因素和影响因子的CK方法是小区域苏仙区2012年、2016年肺癌死亡率最优插值方法,应用该方法可对区域性癌症防控工作的有效开展提供最优的技术支撑。本论文的研究思路也可为小区域癌症数据空间插值方法及参数优选提供参考。

关键词: 小区域, 癌症死亡率, 空间插值

Abstract:

Cancer has become a major livelihood problem endangering the health of global residents. And selecting an appropriate spatial interpolation method to analyze the spatial characteristics of cancer data in a small area can provide a basis for the effective development of regional cancer prevention and control efforts. In this study, we took the 2012 and 2016 lung cancer mortality data in Suxian District of Hunan Province as the research object, and used the average error and the root mean square error as the evaluation indicators. Five typical spatial interpolation methods, namely, inverse distance weighting (IDW), ordinary kriging (OK), trend surface analysis (TSA), multiple linear regression (MLR) and co-kriging (CK), were compared in terms of accuracy and effectiveness and parameter optimization. And then the optimal interpolation method for cancer data was determined in combination of the advantages and disadvantages of different interpolation methods. The results showed that: in terms of interpolation accuracy, the co-kriging (CK) method had the lowest root mean square error of lung cancer mortality in any year, with the interpolation accuracy being the highest, followed by ordinary kriging (OK), inverse distance weighting (IDW) (power=1) and multiple linear regression (MLR), while trend surface analysis (TSA) (order=5) had the lowest root mean square error; in terms of interpolation effect, the measured and predicted values of the five interpolation methods were significantly correlated, except for co-kriging (CK), the other four methods had a greater degree of underestimation of mortality, and the spatial distribution of co-kriging (CK) and ordinary kriging (OK) interpolation results were better. The co-kriging (CK) method, which considers both spatial factors and impact factors, is the optimal interpolation method for lung cancer mortality in 2012 and 2016 in the study area. The application of this method can provide the optimal technical support for the effective implementation of regional cancer prevention and control. This paper can also provide a great reference for the spatial interpolation method and parameter optimization of small area cancer data.

Key words: small area, cancer mortality, spatial interpolation method

王士博, 王勇. 小区域癌症数据典型空间插值方法比较研究[J]. 地理研究, 2021, 40(7): 2102-2118.

WANG Shibo, WANG Yong. Comparative research on typical spatial interpolation methods for cancer data in small regions[J]. GEOGRAPHICAL RESEARCH, 2021, 40(7): 2102-2118.

图/表 12

图1

表1

图2

图3

表2

表3

表4

表5

表6

图4

图5

图6

参考文献 33

[1]	Bray F, Ferlay J, Soerjomataram I, et al. Global cancer statistics 2018: GLOBOCAN estimates of incidence and mortality Worldwide for 36 cancers in 185 countries. CA-A Cancer Journal for Clinicians, 2018, 68(6): 394-424. DOI: 10.3322/caac.21609. doi: 10.3322/caac.v68.6
[2]	Chen Wanqing, Xia Changfa, Zheng Rongshou, et al. Disparities by province, age, and sex in site-specific cancer burden attributable to 23 potentially modifiable risk factors in China: A comparative risk assessment. Lancet Glob Health, 2019, 7(2): e257-e269. DOI: 10.1016/s2214-109x(18)30488-1. doi: 10.1016/S2214-109X(18)30488-1
[3]	Etzel C, Zhang Q, Schabath M, et al. Building a comprehensive quantitative risk assessment model for lung cancer. Lung Cancer, 2005, 49(2): S21-S21. DOI: 10.1016/S0169-5002(05)80185-0.
[4]	王佳欣, 胡茂桂, 于石成, 等. 基于面到面泊松克里格方法的手足口病发病率空间分布降尺度研究. 中华流行病学杂志, 2017, 38(9): 1201-1205.
	[ Wang Jiaxin, Hu Maogui, Yu Shicheng, et al. Downscaling research of spatial distribution of incidence of hand foot and mouth disease based on area-to-area Poisson Kriging method. Chinese Journal of Epidemiology, 2017, 38(9): 1201-1205.]. DOI: 10.3760/cma.j.issn.0254-6450.2017.09.012.
[5]	曲宸绪, 姜勇, 武燕萍, 等. 使用反距离权重内插法绘制中国1990年代肿瘤分布地图. 中华流行病学杂志, 2006, 27(3): 230-233.
	[ Qu Chenxu, Jiang Yong, Wu Yanping, et al. Study on the development of a choropleth atlas on cancer mortality using the inverse distance weight interpolation in the 1990′s. Chinese Journal of Epidemiology, 2006, 27(3): 230-233.]. DOI: 10.3760/j.issn:0254-6450.2006.03.011.
[6]	Smith ND, Prasad SM, Patel AR, et al. Bladder cancer mortality in the United States: A geographic and temporal analysis of socioeconomic and environmental factors. Journal of Urology, 2016, 195(2): 290-296. DOI: 10.1016/j.juro.2015.07.091. doi: 10.1016/j.juro.2015.07.091
[7]	Bristow RE, Chang J, Ziogas A, et al. Spatial analysis of advanced-stage ovarian cancer mortality in California. American Journal of Obstetrics and Gynecology, 2015, 213(1): 43.e1-43.e8. DOI: 10.1016/j.ajog.2015.01.045. doi: 10.1016/j.ajog.2015.01.045
[8]	Chen Yixian, Jiang Xiaosan, Wang Yong, et al. Spatial characteristics of heavy metal pollution and the potential ecological risk of a typical mining area: A case study in China. Process Safety & Environmental Protection, 2018, 113: 204-219. DOI: 10.1016/j.psep.2017.10.008.
[9]	Wang Fahui. Spatial clusters of cancers in Illinois 1986-2000. Journal of Medical Systems, 2004, 28(3): 237-56. DOI: 10.1023/b:joms.0000032842.7864.38. pmid: 15446615
[10]	Goovaerts P. Geostatistical analysis of disease data: Accounting for spatial support and population density in the isopleth mapping of cancer mortality risk using area-to-point Poisson kriging. International Journal of Health Geographics, 2006, 5: 52-82. DOI: 10.1186/1476-072X-5-52. pmid: 17137504
[11]	Ding Qian, Cheng Gong, Wang Yong, et al. Effects of natural factors on the spatial distribution of heavy metals in soils surrounding mining regions. Science of the Total Environment, 2017, 578: 577-585. DOI: 10.1016/j.scitotenv.2016.11.001. doi: 10.1016/j.scitotenv.2016.11.001
[12]	Song Daping, Jiang Dong, Wang Yong, et al. Study on association between spatial distribution of metal mine and disease mortality: A case study in Suxian Diatrict, South China. International Journal of Environmental Research and Public Health, 2013, 10(10): 5163-5177. DOI: 10.3390/ijerph10105163. doi: 10.3390/ijerph10105163
[13]	徐新良. 中国年度植被指数(NDVI)空间分布数据集. 中国科学院资源环境科学数据中心数据注册与出版系统(http://www.resdc.cn/DOI ) , 2018.
	[ Xu Xinliang. China Annual Vegetation Index (NDVI) Spatial Distribution Data Set. Data Registration and Publishing System of the Resource and Environmental Science Data Center of the Chinese Academy of Sciences, http://www.resdc.cn/DOI, 2018.]. DOI: 10.12078/2018060601.
[14]	徐新良. 中国GDP空间分布公里网格数据集. 中国科学院资源环境科学数据中心数据注册与出版系统(http://www.resdc.cn/DOI ) , 2017.
	[ Xu Xinliang. China's GDP spatial distribution kilometer grid dataset. Data Registration and Publishing System of the Resource and Environmental Science Data Center of the Chinese Academy of Sciences(http://www.resdc.cn/DOI ) , 2017.]. DOI: 10.12078/2017121102.
[15]	Zhuang Dafang, Du Haiwen, Wang Yong, et al. Probing the spatial cluster of Meriones unguiculatus using the nest flea index based on GIS technology. Acta Tropica, 2016, 163: 157-166. DOI: 10.1016/j.actatropica.2016.08.007. doi: 10.1016/j.actatropica.2016.08.007
[16]	王劲峰, 廖一兰, 刘鑫. 空间数据分析教程. 北京: 科学出版社, 2010.
	[ Wang Jinfeng, Liao Yilan, Liu Xin. Spatial Data Analysis Tutorial. Beijing: Science Press, 2010.]
[17]	赵颖慧, 吕泓辰, 甄贞, 等. 黑龙江省气象因子插值优化及与落叶松NPP相关性分析. 南京林业大学学报(自然科学版), 2018, 42(3): 1-9.
	[ Zhao Yinghui, Lv Hongchen, Zhen Zhen, et al. Interpolation optimization of meteorological factors and its correlation analysis with the larch NPP in Heilongjiang province, China. Journal of Nanjing Forestry University (Natural Sciences Edition), 2018, 42(3): 1-9.]. DOI: 10.3969/j.issn.1000-2006.201709002.
[18]	牛腾, 岳德鹏, 李倩, 等. 基于GLM-PSO-coKriging模型的地表形变研究. 地球信息科学学报, 2018, 20(11): 43-55.
	[ Niu Teng, Yue Depeng, Li Qian, et al. Research on surface deformation based on GLM-PSO-coKriging model. Journal of Geo-information Science, 2018, 20(11): 43-55.]. DOI: 10.12082/dqxxkx.2018.180289.
[19]	Ghanbarpour M R, Goorzadi M, Vahabzade G. Spatial variability of heavy metals in surficial sediments: Tajan River Watershed, Iran. Sustainability of Water Quality and Ecology, 2013, 1-2: 48-58. DOI: 10.1016/j.swaqe.2014.04.002. doi: 10.1016/j.swaqe.2014.04.002
[20]	Wong Tzu-Tsung. Performance evaluation of classification algorithms by k-fold and leave-one-out cross validation. Pattern Recognition, 2015, 48(9): 2839-2846. DOI: 10.1016/j.patcog.2015.03.009. doi: 10.1016/j.patcog.2015.03.009
[21]	Arslan H, Turan N A. Estimation of spatial distribution of heavy metals in groundwater using interpolation methods and multivariate statistical techniques; its suitability for drinking and irrigation purposes in the Middle Black Sea Region of Turkey. Environmental Monitoring and Assessment, 2015, 187(8): 516. DOI: 10.1007/s10661-015-4725-x. doi: 10.1007/s10661-015-4725-x pmid: 26202813
[22]	王幼奇, 白一茹, 王建宇. 基于GIS的银川市不同功能区土壤重金属污染评价及分布特征. 环境科学, 2016, 37(2): 710-716.
	[ Wang Youqi, Bai Yiru, Wang Jianyu. Distribution of urban soil heavy metal and pollution evaluation in different functional zones of Yinchuan city. Environmental Science, 2016, 37(2): 710-716.]. DOI: 10.13227/j.hjkx.2016.02.041.
[23]	Oleksii Motorykin, Melissa M. Matzke, Katrina M. Waters, et al. Association of carcinogenic polycyclic aromatic hydrocarbon emissions and smoking with lung cancer mortality rates on a global scale. Environmental Science & Technology, 2013, 47(7): 3410-3416. DOI: 10.1021/es305295d. doi: 10.1021/es305295d
[24]	Haoran Z, Nitin Kumar Tripathi. Geospatial hot spot analysis of lung cancer patients correlated to fine particulate matter (PM 2.5) and industrial wind in Eastern Thailand. Journal of Cleaner Production, 2018, 170: 407-424. DOI: 10.1016/j.jclepro.2017.09.185. doi: 10.1016/j.jclepro.2017.09.185
[25]	黄群茵, 张奕彩, 陈映融, 等. 应用空间资讯技术以探讨环境绿蔽度与肺癌发生之关联: 以大台北及大嘉义地区为例. 航测及遥测学刊, 2019, 24(1): 13-24.
	[ Huang Qunyin, Zhang Yicai, Chen Yingrong, et al. Association between surrounding greenness and lung cancer incidence using geospatial information technologies: A case study of Taipei and Chiayi areas. Journal of Photogrammetry and Remote Sensing, 2019, 24(1): 13-24.]. DOI: 10.6574/JPRS.201903_24(1).0002.
[26]	卢月明, 王亮, 仇阿根, 等. 一种基于主成分分析的协同克里金插值方法. 测绘通报, 2017, (11): 51-57.
	[ Lu Yueming, Wang Liang, Qiu Agen, et al. A CoKriging Interpolation Method based on principal component analysis. Bulletin of Surveying and Mapping, 2017, (11): 51-57.]. DOI: 10.13474/j.cnki.11-2246.2017.0347.
[27]	Ji Wei, Wang Yong, Zhuang Dafang. Spatial distribution differences in PM_2.5 concentration between heating and non-heating seasons in Beijing, China. Environmental Pollution, 2019, 24: 574-583. DOI: 10.1016/j.envpol.2019.01.002.
[28]	颜仕鹏, 许可葵, 肖海帆, 等. 2010-2015年湖南省恶性肿瘤空间流行病学特征分析. 中国肿瘤, 2019, 28(11): 832-837.
	[ Yan Shipeng, Xu Kekui, XIAO Haifan, et al. Spatial epidemiology of malignant tumors in Hunan province from 2010 to 2015. China Cancer, 2019, 28(11): 832-837.]. DOI: 10.11735/j.issn.1004-0242.2019.11.A005.
[29]	Ding Qian, Wang Yong, Zhuang Dafang. Comparison of the common spatial interpolation methods used to analyze potentially toxic elements surrounding mining regions. Journal of Environmental Management, 2018, 212: 23-31. DOI: 10.1016/j.jenvman.2018.01.074. doi: 10.1016/j.jenvman.2018.01.074
[30]	Zhen Jinchun, Pei Tao, Xie Shuyun. Kriging methods with auxiliary nighttime lights data to detect potentially toxic metals concentrations in soil. Science of the Total Environment, 2019, 659: 363-371. DOI: 10.1016/j.scitotenv.2018.12.330. doi: 10.1016/j.scitotenv.2018.12.330
[31]	倪书华. 空间统计学及其在公共卫生领域中的应用. 汕头大学学报(自然科学版), 2014, 29(4): 61-67.
	[ Ni Shuhua. Spatial statistics and its application in the field of public health. Journal of Shantou University (Natural Science), 2014, 29(4): 61-67. ]. DOI: CNKI:SUN:STDX.0.2014-04-010.
[32]	Sahar Hassani, Harald Martens, EI Mostafa Qannari, et al. Degrees of freedom estimation in principal component analysis and consensus principal component analysis. Chemometrics and Intelligent Laboratory Systems, 2012, 118: 246-259. DOI: 10.1016/j.chemolab.2012.05.015. doi: 10.1016/j.chemolab.2012.05.015
[33]	Kay Sumfleth, Rainer Duttmann. Prediction of soil property distribution in paddy soil landscapes using terrain data and satellite information as indicators. Ecological Indicators, 2008, 8(5): 485-501. DOI: 10.1016/j.ecolind.2007.05.005. doi: 10.1016/j.ecolind.2007.05.005

	最大值（/10万）	最小值（/10万）	平均值（/10万）	标准差（/10万）	变异系数
2012年	274.66	3.18	35.29	30.22	0.856
2016年	252.27	11.53	34.41	25.32	0.736

影响因素	相关系数		容忍度	方差膨胀因子
影响因素	2012年	2016年	容忍度	方差膨胀因子
到河流距离	-0.194*	-0.249**	0.455	2.200
到道路距离	-0.092	-0.229*	0.450	2.220
到采矿场距离	-0.129	-0.234*	0.222	4.508
人口密度	0.025	0.249*	0.262	3.818
地区生产总值	0.352**	0.295**	0.154	6.477
高程	0.208*	-0.340*	0.110	9.111
坡度	0.127*	-0.394**	0.128	7.796
植被覆盖度	-0.164	-0.464**	0.288	3.473
年均温度	-0.138	0.470*	0.186	5.366
年均降雨	0.394**	-0.065	0.369	2.708
年均相对湿度	-0.059	-0.199**	0.118	8.504
年均相对气压	-0.297**	0.133**	0.171	5.855
PM2.5	0.126	0.272**	0.141	7.084
Cd	-0.204*	-0.208*	0.513	1.949

	插值方法	插值参数			平均误差ME	均方根误差RMSE
2012年	反距离加权插值（IDW）	幂值 = 1			0.044	0.616
		幂值 = 2			0.033	0.619
		幂值 = 3			0.028	0.617
	趋势面分析（TSA）	多项式的阶 = 3			-0.005	0.727
		多项式的阶 = 4			-0.005	0.702
		多项式的阶 = 5			0.001	0.701
		多项式的阶 = 6			0.012	0.703
	普通克里金插值（OK）	块金常数C₀	偏基台值 C	变程 Range
	球状Spherical	0.058	0.737	14506.22	0.003	0.620
	指数Exponential	0.001	0.837	18262.84	0.002	0.620
	高斯Gaussian	0.181	0.619	12601.85	0.004	0.615
2016年	反距离加权插值（IDW）	幂值 = 1			0.001	0.800
		幂值 = 2			0.021	0.807
		幂值 = 3			0.044	0.851
	趋势面分析（TSA）	多项式的阶 = 3			-0.004	0.946
		多项式的阶 = 4			-0.004	0.962
		多项式的阶 = 5			0.005	0.886
		多项式的阶 = 6			-0.020	0.988
	普通克里金插值（OK）	块金常数C₀	偏基台值 C	变程 Range
	球状Spherical	0.016	1.160	10321.07	-0.009	0.813
	指数Exponential	0.010	1.240	13383.30	-0.007	0.803
	高斯Gaussian	0.244	0.954	9386.33	-0.001	0.826

	影响因素	参数估计	t	p
2012年	截距	383.236	6.839	0.000
	到河流距离	-0.410	-4.422	0.000
	高程	-0.425	-2.524	0.013
	坡度	0.321	1.934	0.050
	人口密度	-0.293	-2.441	0.016
	地区生产总值	0.216	1.466	0.014
	年均相对气压	-1.122	-7.851	0.000
	年均温度	-0.281	-2.199	0.030
	到矿区距离	0.371	2.848	0.005
	植被覆盖度	-0.260	-2.260	0.026
	年均相对湿度	0.580	3.438	0.001
2016年	截距	-97.284	-3.028	0.003
	到道路距离	0.164	1.558	0.022
	高程	-0.401	-2.867	0.005
	地区生产总值	0.195	2.065	0.041
	到矿区距离	-0.339	-3.445	0.001
	年均相对湿度	0.596	2.333	0.021
	年均温度	1.157	3.528	0.001
	年均降雨	0.692	3.600	0.000
	Cd	-0.395	-1.997	0.048

	类别	第一主成分	第二主成分	第三主成分	第四主成分	第五主成分	第六主成分	第七主成分
2012年	特征值	4.73600	2.22700	1.28400	0.61000	0.27300	0.11200	0.07300
	贡献度	0.57326	0.27054	0.07629	0.02934	0.02093	0.01745	0.01219
	累计贡献度	0.57326	0.84380	0.92009	0.94943	0.97036	0.98781	1
2016年	特征值	2.96600	1.87900	0.73000	0.66200	0.29200	0.15700	0.07000
	贡献度	0.57494	0.29225	0.07082	0.03242	0.01746	0.00783	0.00399
	累计贡献度	0.57494	0.86749	0.93831	0.97072	0.98818	0.99601	1
