新疆昌吉州耕地土壤有机质空间变异动态研究

doi:10.11821/dlyj020200915

地理研究 ›› 2021, Vol. 40 ›› Issue (3): 643-656.doi: 10.11821/dlyj020200915

• 专栏：绿洲耕地可持续利用 • 上一篇下一篇

新疆昌吉州耕地土壤有机质空间变异动态研究

张兆彤¹^,²(), 李源³, 刘国宏³, 朱倩倩³, 许咏梅³()

1.中国科学院地理科学与资源研究所陆地表层格局与模拟重点实验室,北京 100101
2.中国科学院大学,北京 100049
3.新疆农科院土壤肥料与农业节水研究所,乌鲁木齐 830091

收稿日期:2020-09-22 接受日期:2021-02-03 出版日期:2021-03-10 发布日期:2021-05-10
通讯作者: 许咏梅
作者简介:张兆彤（1994-）,女,山东济南人,博士研究生,主要从事土地利用变化及其环境效应研究。E-mail: zhangzt.19b@igsnrr.ac.cn
基金资助:
国家自然科学基金项目(41561070);国家产业技术体系(CARS-170202)

Dynamic research on spatial variability of cultivated soil organic matter in Changji Prefecture, Xinjiang

ZHANG Zhaotong¹^,²(), LI Yuan³, LIU Guohong³, ZHU Qianqian³, XU Yongmei³()

1. Key Laboratory of Land Surface Pattern and Simulation, Institute of Geographic Sciences and Natural Resources Research, CAS, Beijing 100101, China
2. University of Chinese Academy of Sciences, Beijing 100049, China
3. Institute of Soil, Fertilizer and Agricultural Water Reduction, Xinjiang Academy of Agricultural Sciences, Urumqi 830091, China

Received:2020-09-22 Accepted:2021-02-03 Online:2021-03-10 Published:2021-05-10
Contact: XU Yongmei

摘要/Abstract

摘要：

土壤有机质在提高土壤肥力和作物生产力方面发挥重要作用,研究其空间变异性可为精准施肥以及可持续的土地利用和管理提供科学依据。本文以新疆昌吉州为研究区,基于多重分形方法,使用第二次土壤普查（1980年前后）、2010年和2018年共3期土壤有机质数据,计算多重分形参数来探究土壤有机质空间变异的动态。结果表明：① 第二次土壤普查—2018年期间,昌吉州土壤有机质含量呈增加趋势。② 第二次土壤普查—2018年期间,昌吉州土壤有机质的空间分布总体上具有非均匀的多重分形特征,土壤有机质值域范围逐渐变窄,空间分布变异性降低,趋于均一化。其中阜康市、吉木萨尔县和木垒哈萨克自治县的有机质变异程度在2010—2018年略有上升。③ 2018年,昌吉州土壤有机质在空间上自西向东值域分布范围逐渐变宽,变异程度增加,内部差异变大,趋向于非均匀化。④ 三个时期昌吉州土壤有机质数值中均是低值数据分布概率较大,其变异程度高于高值数据,仅阜康市和木垒哈萨克自治县在2018年由高值数据占主导地位。长时间的耕作经营使得土壤有机质含量有所提高,空间分布逐渐趋向均一化,但仍存在部分区域有机质较高,部分区域较低的情况。分区管理措施可以有效提高区域的整体肥力水平,应在阜康市、吉木萨尔县和木垒哈萨克自治县等有机质变异程度较高的区域继续推进精准施肥,改进灌溉和耕作措施以降低土壤有机质空间变异性。

关键词: 耕地土壤有机质, 空间变异, 新疆昌吉州, 多重分形

Abstract:

Soil organic matter (SOM) plays an important role in improving soil fertility and crop productivity, and studying its spatial variability can provide a scientific basis for targeted fertilization and sustainable land use and management. This paper selected Changji Prefecture of Xinjiang as the study area, and used three-stage SOM data (the second soil survey, 2010 and 2018) to calculate the generalized dimension spectrum D(q), multifractal singularity index ɑ(q) and the multifractal spectrum function f(ɑ(q)) based on the multifractal method to explore the dynamic changes of SOM spatial variability. The results showed that: (1) The average SOM contents in the three periods were 10.46, 16.69 and 18.16 g/kg, respectively, showing an upward trend. However, the SOM contents of all counties were lower than the national average level (24.30 g/kg) in 2018. (2) The spatial distribution of SOM in Changji Prefecture had non-uniform multifractal characteristics from the second soil survey to 2018. The distribution range of SOM value gradually became narrowed, and the spatial distribution variability decreased, tending to be uniform. The degree of SOM spatial variability in Fukang city, Jimusaer county, and Mulei Kazakh autonomous county increased slightly from 2010 to 2018. (3) In 2018, the spatial distribution range of SOM widened from west to east, with an increasing variation degree, and internal differences became larger, tending to be non-uniform. (4) In the three periods, all the low-value data had a greater variability, with the variation degree being higher than that of the high-value data. Fukang and Mulei were dominated by the high-value data in 2018. Long-term farming had increased the SOM content, and the spatial distribution gradually tended to be uniform. However, there was obvious spatial heterogeneity of SOM. It is necessary to adopt targeted approaches to improve overall soil fertility in different parts of the study area. It is recommended to promote targeted fertilization and to improve irrigation and farming measures in the places with high spatial variability of organic matter, such as Fukang, Jimusaer and Mulei.

Key words: cultivated soil organic matter, spatial variation, Changji Prefecture,Xinjiang, multi-fraction

张兆彤, 李源, 刘国宏, 朱倩倩, 许咏梅. 新疆昌吉州耕地土壤有机质空间变异动态研究[J]. 地理研究, 2021, 40(3): 643-656.

ZHANG Zhaotong, LI Yuan, LIU Guohong, ZHU Qianqian, XU Yongmei. Dynamic research on spatial variability of cultivated soil organic matter in Changji Prefecture, Xinjiang[J]. GEOGRAPHICAL RESEARCH, 2021, 40(3): 643-656.

图/表 15

图1

图2

图3

表1

表2

表3

图4

图5

图6

图7

图8

图9

图10

图11

参考文献 37

[1]	黄元仿, 周志宇, 苑小勇, 等. 干旱荒漠区土壤有机质空间变异特征. 生态学报, 2004,24(12):2776-2781.
	[ Huang Yuanfang, Zhou Zhiyu, Yuan Xiaoyong, et al. Spatial variability of soil organic matter content in an arid desert area. Acta Ecologica Sinica, 2004,24(12):2776-2781.]. DOI: 10.3321/j.issn: 1000-0933.2004.12.015.
[2]	陈思明, 王宁, 秦艳芳, 等. 河口湿地不同土层有机质的水平异质性与自相关性. 生态学杂志, 2019,38(9):2805-2812.
	[ Chen Siming, Wang Ning, Qin Yanfang, et al. Horizontal variability and autocorrelation of soil organic matter at different soil layers in estuarine wetland. Chinese Journal of Ecology, 2019,38(9):2805-2812.]. DOI: 10.13292/j.1000-4890.201909.010.
[3]	张娜, 张红玲, 屈忠义, 等. 内蒙古河套灌区不同土层有机质空间变异的分形. 干旱地区农业研究, 2017,35(5):157-163.
	[ Zhang Na, Zhang Hongling, Qu Zhongyi, et al. Fractal study on organic matter spatial heterogeneity of different soil layers in Inner Mongolia Hetao Irrigation District. Agricultural Research in the Arid Areas, 2017,35(5):157-163.]. DOI: 10.7606/j.issn.1000-7601.2017.05.23.
[4]	张法升, 刘作新. 分形理论及其在土壤空间变异研究中的应用. 应用生态学报, 2011,22(5):1351-1358.
	[ Zhang Fasheng, Liu Zuoxin. Fractal theory and its application in the analysis of soil spatial variability: A review. Chinese Journal of Applied Ecology, 2011,22(5):1351-1358.]
[5]	高凤杰, 马泉来, 韩文文, 等. 黑土丘陵区小流域土壤有机质空间变异及分布格局. 环境科学, 2016,37(5):325-332.
	[ Gao Fengjie, Ma Quanlai, Han Wenwen, et al. Spatial variability and distribution pattern of soil organic matter in a mollisol watershed of China. Environmental Science, 2016,37(5):325-332.]
[6]	谢红花, 李超, 钱晔, 等. 云南乌蒙山区土壤养分空间变异及海拔梯度分布规律. 中国农学通报, 2019,35(8):52-59.
	[ Xie Honghua, Li Chao, Qian Ye, et al. Spatial variability and altitudinal gradient distribution pattern of soil mutrients in Wumeng mountainous region, Yunnan. Chinese Agricultural Science Bulletin, 2019,35(8):52-59.]
[7]	Hu K, Wang S Y, Li H, et al. Spatial scaling effects on variability of soil organic matter and total nitrogen in suburban Beijing. Geoderma, 2014, 226-227:54-63. DOI: 10.1016/j.geoderma.2014.03.001.
[8]	Wang Z M, Zhang B, Song K S, et al. Spatial variability of soil organic carbon under maize monoculture in the Song-nen Plain, Northeast China. Pedosphere, 2010,20(1):80-89.
[9]	赵明松, 张甘霖, 王德彩, 等. 徐淮黄泛平原土壤有机质空间变异特征及主控因素分析. 土壤学报, 2013,50(1):1-11.
	[ Zhao Mingsong, Zhang Ganlin, Wang Decai, et al. Spatial variability of soil organic matter and its dominating factors in Xu-huai alluvial plain. Acta Pedologica Sinica, 2013,50(1):1-11.]
[10]	张敏, 贺鹏飞, 陈伟强. 基于GIS和地统计学的土壤养分空间变异分析. 东北农业大学学报, 2010,41(3):53-58.
	[ Zhang Min, He Pengfei, Chen Weiqiang. Spatio-temporal variability analysis of soil nutrients based on GIS and Geostatistics. Journal of Northeast Agricultural University, 2010,41(3):53-58.]. DOI: 10.3969/j.issn.1005-9369.2010.03.012.
[11]	Mabit L, Bernard C, Makhlouf M, et al. Spatial variability of erosion and soil organic matter content estimated from 137Cs measurements and geostatistics. Geoderma, 2008,145(3-4):245-251. DOI: 10.1016/j.geoderma.2008.03.013.
[12]	Marchetti A, Piccini C, Francaviglia R, et al. Spatial distribution of soil organic matter using geostatistics: A key indicator to assess soil degradation status in central Italy. Pedosphere, 2012,22(2):230-242. DOI: 10.1016/S1002-0160(12)60010-1.
[13]	徐冰, 赵淑银, 郭克贞. 分形地统计学及其在土壤科学中的应用. 土壤通报, 2009,40(6):224-228.
	[ Xu Bing, Zhao Shuyin, Guo Kezhen. Fractal geostatistics and its applications in soil sciences. Chinese Journal of Soil Science, 2009,40(6):224-228.]
[14]	徐冰. 基于分形地质统计学的草地土壤空间变异. 内蒙古: 内蒙古农业大学博士学位论文, 2009: 1.
	[ Xu Bing. Spatial variability of soil in grassland base on fractal geostatistics theory. Inner Mongolia Autonomous Region: Doctoral Dissertation of Inner Mongolia Agricultural University, 2009: 1.]
[15]	管孝艳, 杨培岭, 吕烨. 基于多重分形理论的农田土壤特性空间变异性分析. 应用基础与工程科学学报, 2011,19(5):712-720.
	[ Guan Xiaoyan, Yang Peiling, Lv Ye. Analysis on spatial variability of soil properties based on multifractal theory. Journal of Basic Science and Engineering, 2011,19(5):712-720.]. DOI: 10.3969/j.issn.1005-0930.2011.05.003.
[16]	王宇. 基于多重分形理论的黄土区露天煤矿排土场重构土壤特性空间变异研究. 北京: 中国地质大学(北京)硕士学位论文, 2015: 10.
	[ Wang Yu. Spatial variability of reconstructed soil properties in opencast coal mine dump in loess area based on multi-fractal theory. Beijing: Master Dissertation of China University of Geosciences (Beijing ), 2015: 10.]
[17]	Wang F J, Wang J M, Wang Y. Using multi-fractal and joint multi-fractal methods to characterize spatial variability of reconstructed soil properties in an opencast coal-mine dump in the Loess area of China. Catena, 2019,182. DOI: 10.1016/j.catena.2019.104111.
[18]	王子龙, 孙建, 姜秋香, 等. 松嫩平原黑土区有机质空间分布特征及影响因素. 东北农业大学学报, 2019,50(10):54-62.
	[ Wang Zilong, Sun Jian, Jiang Qiuxiang, et al. Spatial distribution characteristics and influencing factors of organic matter in black soil region of the Songnen Plain. Journal of Northeast Agricultural University, 2019,50(10):54-62.]. DOI: 10.19720/j.cnki.issn.1005-9369.2019.10.007.
[19]	张佳瑞, 王金满, 秦倩, 等. 基于CT扫描的煤矿排土场土壤孔隙三维多重分形特征. 土壤通报, 2017,48(4):786-793.
	[ Zhang Jiarui, Wang Jinman, Qin Qian, et al. Three-dimensional multi- fractal characteristics of reconstruction soil pore at opencast coal mine dump based on CT scanning. Chinese Journal of Soil Science, 2017,48(4):786-793.]. DOI: 10.19336/j.cnki.trtb.2017.04.03.
[20]	张兴义, 王禹宸, 李浩, 等. 黑土坡耕地水保措施下土壤水分时空变异分析. 东北农业大学学报, 2014,45(11):59-64.
	[ Zhang Xingyi, Wang Yuchen, Li Hao, et al. Spatial-temporal variation of soil moisture under the soil and water conservation in black soil sloping farmland. Journal of Northeast Agricultural University, 2014,45(11):59-64.]. DOI: 10.3969/j.issn.1005-9369.2014.11.009.
[21]	Black K, Creamer R E, Xenakis G, et al. Improving forest soil carbon models using spatial data and geostatistical approaches. Geoderma, 2014, 232-234(12):487-499. DOI: 10.1016/j.geoderma.2014.05.022.
[22]	Wang J M, Wang H D, Cao Y G, et al. Effects of soil and topographic factors on vegetation restoration in opencast coal mine dumps located in a loess area. Scientific Reports, 2016,6(1):233-238. DOI: 10.1038/srep22058.
[23]	Meneveau C, Sreenivasan K R, Kailasnath P, et al. Joint multifractal measures: Theory and applications to turbulence. Physical Review A, 1990,41(2):894. DOI: 10.1103/PhysRevA.41.894.
[24]	Lee C K. Multifractal characteristics in air pollutant concentration time series. Water, Air, and Soil Pollution, 2002,135(1-4):389-409. DOI: 10.1023/A: 1014768632318.
[25]	Perfect E, Tarquis A M, Bird N R A. Accuracy of generalized dimensions estimate from grayscale images using the method of moments. Fractals, 2009,17(3):351-363. DOI: 10.1142/S0218348X09004302.
[26]	白一茹, 汪有科. 黄土丘陵区土壤粒径分布单重分形和多重分形特征. 农业机械学报, 2012,43(5):43-48, 42.
	[ Bai Yiru, Wang Youke. Monofractal and multifractal analysis on soil particle distribution hilly and gully areas of the loess plateau. Transactions of the Chinese Society for Agricultural Machinery, 2012,43(5):43-48, 42.]. DOI: 10.6041/j.issn.1000-1298.2012.05.008.
[27]	Martn M A, Montero E. Laser diffraction and multifractal analysis for the characterization of dry soil volume-size distributions. Soil and Tillage Research, 2002,64(1-2):113-123. DOI: 10.1016/S0167-1987(01)00249-5.
[28]	Ferreiro J P, Vidal Vázquez E. Multifractal analysis of Hg pore size distributions in soils with contrasting structural stability. Geoderma, 2010,160(1):64-73. DOI: 10.1016/j.geoderma.2009.11.019.
[29]	Gibson J R, Lin H, Bruns M A. A comparison of fractal analytical methods on 2-and 3-dimensional computed tomographic scans of soil aggregates. Geoderma, 2006,134(3-4):335-348. DOI: 10.1016/j.geoderma.2006.03.052.
[30]	Zeleke T B, Si B C. Characterizing scale-dependent spatial relationships between soil properties using multifractal techniques. Geoderma, 2006,134(3-4):440-452. DOI: 10.1016/j.geoderma.2006.03.013.
[31]	宋莎, 李廷轩, 王永东, 等. 县域农田土壤有机质空间变异及其影响因素分析. 土壤, 2011,43(1):44-49.
	[ Song Sha, Li Tingxuan, Wang Yongdong, et al. Spatial variabity of soil organic matter and its influencing factors at county scales. Soils, 2011,43(1):44-49.]
[32]	苑小勇, 黄元仿, 高如泰, 等. 北京市平谷区农用地土壤有机质空间变异特征. 农业工程学报, 2008,24(2):70-76.
	[ Yuan Xiaoyong, Huang Yuanfang, Gao Rutai, et al. Spatial variability characteristics of farmland soil organic matter in Pinggu District, Beijing, China. Transactions of the CSAE, 2008,24(2):70-76.]. DOI: 10.3321/j.issn: 1002-6819.2008.02.013.
[33]	李龙, 姜丽娜, 白建华. 半干旱区土壤有机碳空间变异及其影响因素的多尺度相关分析. 中国水土保持科学, 2018,16(5):40-48.
	[ Li Long, Jiang Lina, Bai Jianhua. Multi-scale correlations between spatial variability of soil organic carbon and its influencing factors in semiarid zone. Science of Soil and Water Conservation, 2018,16(5):40-48.]. DOI: 10.16843/j.sswc.2018.05.006.
[34]	张法升, 刘作新, 曲威, 等. 长期耕作条件下小尺度农田土壤有机质空间变异性. 干旱地区农业研究, 2010,28(2):167-171.
	[ Zhang Fasheng, Liu Zuoxin, Qu Wei, et al. Spatial variability of soil organic matter in long-termsmall scale across cultivated crop land. Agricultural Research in the Arid Areas, 2010,28(2):167-171.]
[35]	Kravehenko A N, Charles W B, Donald G B. Multifractal analysis of soil spatial variability. Agronomy Joumal, 1999,91:1033-1041. DOI: 10.2134/agronj1999.9161033x.
[36]	Peyton R L, Gantzer C J, Anderson S H, et al. Fractal dimension to describe soil macropore structure using X-ray computed tomography. Water Resources Research, 1994,30(3):691-700. DOI: 10.1029/93wr02343.
[37]	周虎, 李保国, 吕贻忠, 等. 不同耕作措施下土壤孔隙的多重分形特征. 土壤学报, 2010,47(6):1094-1100.
	[ Zhou Hu, Li Baoguo, Lv Yizhong, et al. Multifractal characteristics of soil pore structure under different tillage systems. Acta Pedologica Sinica, 2010,47(6):1094-1100.]

市县名	2010年样点数	2018年样点数
昌吉市	6434	149
阜康市	1742	64
呼图壁县	2649	130
吉木萨尔县	4998	112
玛纳斯县	5357	154
木垒哈萨克自治县	2101	10
奇台县	2929	136
总计	26210	755

参数类型	参数名称	含义	表征意义
广义维数谱	D₀	容量维数	表征研究变量的值域范围,D₀越大,值域范围越宽
广义维数谱	ΔD=D_max-D_min	谱宽	代表广义维数谱弯曲程度,表征研究变量局部变异程度,ΔD值越大则变异程度越强
多重分形谱	Δα=ɑ_max-ɑ_min	谱宽	表征研究变量空间分布的非均匀程度,Δα值越大则非均匀程度越高
多重分形谱	Δf=f(ɑ_min)-f(ɑ_max)	谱高差	表征子集的最大概率和最小概率之间的对比关系。当Δf <0时,研究变量中低值的变异程度大于高值;当Δf >0时,研究变量中高值数据的变异性程度大于低值数据

时期	昌吉州	昌吉市	阜康市	呼图壁县	吉木萨尔县	玛纳斯县	木垒哈萨克自治县	奇台县
第二次土壤普查(1980年)	10.46	8.06	9.28	11.59	20.48	12.71	9.88	15.34
2010年	16.69	15.37	18.13	14.85	18.29	16.96	12.49	21.27
2018年	18.16	13.33	21.02	13.79	19.83	17.10	16.21	19.29

时期	q=-10		q=-5		q=0		q=5		q=10
时期	K	R²	K	R²	K	R²	K	R²	K	R²
第二次土壤普查(1980年)	-7.9851	0.9911	-4.2293	0.9960	-0.6021	1.0000	2.0526	0.9996	4.5087	0.9998
2010年	-7.3287	0.9971	-3.7652	0.9997	-0.6021	1.0000	2.3337	1.0000	5.0590	0.9999
2018年	-6.8354	0.9997	-3.6709	1.0000	-0.6021	1.0000	2.3277	1.0000	5.0073	0.9996
